The Wall-mounted (Clamp-on) Ultrasonic Flowmeter (Model: SUP-1158S) is an advanced flow measurement device that utilizes ultrasonic technology for precise flow monitoring. This model is designed for various industrial applications and offers high accuracy and flexible integration options. Below are the key specifications:
Pipe Size: DN32-DN6000 (Suitable for a wide range of pipe diameters, from small to large-scale applications).
Accuracy: The flowmeter offers ±1% accuracy, ensuring precise measurements in various liquid flow applications.
Signal Output:
1-way 4-20mA output: For analog signal transmission.
1-way OCT pulse output: For digital pulse signal output.
1-way relays output: For alarm or control system integration.
Interface: The device is equipped with an RS485 interface and supports MODBUS communication protocol for easy integration with industrial control systems.
Liquid Types: Suitable for virtually all liquids, making it versatile for a wide range of industrial fluids.
Working Temperature:
Converter: -20℃ to 60℃.
Flow Transducer: -30℃ to 160℃.
Working Humidity: The converter operates efficiently at 85% RH humidity.
Power Supply:
DC8~36V or AC85~264V (optional), offering flexibility for different power supply configurations.
Data Logger: Built-in data logger that can store over 2000 lines of data for future analysis and record-keeping.
Case Material: The converter is made from ABS, ensuring durability and protection.
Dimensions: The converter has a compact size of 170 x 180 x 56mm.
