The Turbine Flow Sensor (Model: SUP-LWGY) is a precision flow measurement device designed for a wide range of fluid applications. Below are its key specifications:
Diameter Nominal: DN4~DN100 (Suitable for a wide range of pipe sizes).
Nominal Pressure: The sensor is rated for a nominal pressure of 6.3 MPa, allowing it to handle moderate to high-pressure applications.
Accuracy: The accuracy of the flow measurement is 0.5%R (relative accuracy) and 1.0%R (optional), providing reliable performance for most industrial flow measurement applications.
Medium Temperature: The sensor can operate within a medium temperature range of -20℃ to +120℃, making it suitable for various environmental conditions and fluid types.
Power Supply:
3.6V lithium battery (for battery-powered applications),
12 VDC or 24 VDC (for powered installations).
Output Signal:
The device provides multiple output options: Pulse, 4-20mA, and RS485 (with transmitter), enabling integration into a variety of control systems and data acquisition setups.
Ingress Protection: The sensor is rated with IP65 protection, ensuring it is dust-tight and protected from water jets, making it suitable for industrial environments with exposure to dust and moisture.
